True Online Double Conversion
RACK AND TOWER DESIGN
Digital display LCD & LED
Wide input voltage range and frequency tolerance
Power factor 0.9
1 phase In, 1 phase Out
Multi-protections such as overload, short-circuit, over-temperature, battery under voltage, battery overcharge
Transfer time 0 ms
Crest factor 3:1
Pure sine wave output
Automatic restart
Battery cold start function
Maintenance sealed lead acid battery
Advance Battery Management
Back up 15-30 mins (depend on loads)
Extension battery (Optional)
Universal outlet
Software monitoring
SNMP card (optional)
TISI standards 1291-2553(1),TISI standards 1291-2553(2), TISI standards 1291-2555(3),  ISO 9001, ISO 14001, CE, EN, FCC, RoHS
Onsite Service & PM  (According to company policy)

2 Years Warranty
Free Onsite Service at Bangkok Metropolitan Region *Conditions are as specified by the company
Pick-up and delivery of the repair product for free with express delivery.
Service Center has ISO 9001:2015


ZIRCON
The Smart Power Solution ✨​​​​​​​



ZC-RTII



Input	Model Capacity (VA/W) Phase Rated Voltage Voltage Range Frequency Range Power Factor Current THDi Bypass Voltage Range ECO Range Generator Input	3000VA 2700W Single Phase & Ground 200/208/220/230/240VAC 110-290V* 50Hz-60Hz (Auto-Detect) > 0.98 <7% at 100% Non-Linear Load Max. Voltage; -45% Optional -20%~-30% Frequency Protection Range: +/-10% Same As The Bypass Support
Output	Phase Rated Voltage Power Factor ​Voltage Regulation Frequency - Utility Mode                 - Battery Mode Crest Factor THD Wave Form	Single Phase & Ground 200/208/220/230/240VAC 0.9 ​+/- 2% 50Hz or 60Hz (Synchronized to Mains) 50Hz-60Hz  +/- 0.02% Hz 3:1 < 3% with Linear Load < 5% with non  Linear Load Pure Sine Wave
Efficiency	AC Mode ( Full Load ) ​Battery  Mode ( Full Load ) ECO Mode ( Full Load )	Up to 90% >88% ​>94%
Battery	Voltage Capacity (Standard Unit) Back up Time Recharge Time to 90% Charging Current Battery Socket	72Vdc 12V/9Ah Full load 5 min, 15-30 min ( Depend on load), Estimated remaining time display on the LCD 4-5 Hours 1.4A Anderson Like PowerPole Modular Connectors
Transfer Time		Utility to Battery; 0ms, Utility to Bypass <4ms
Protection	Overload   - AC Mode                   - Batt. Mode                   - Bypass Mode Short Circuit Overheat Battery Low Self-Diagnostics EPO Battery Noise Suppression	Load <100%-150%; 30S; Load >150%; 300ms then shutdown UPS completely Load <100%-150%; 30S; Load >150%; 300ms then shutdown UPS completely Load >130%; 60S then shutdown output Hold Whole System Line mode; Switch to Bypass; Battery Mode, shutdown UPS immediately Alarm and Switch off Upon Power On and Software Control Shutdown UPS immediately Advanced Battery Management Compiles with EN962040-2
Display	Status LED & LCD Reading on the LCD	Load/Battery/Input/Output/Operating Mode information Load/Battery/Input/Output/Operating Mode information
Physical	Dimnsion (WxHxD) mm. Weight (Kilogram) Input Connection Output Connection External Battery Connection	440 x 86.5 x 696 18.1 IEC320 C14-10A Universal x 6 IEC320 C19-16A x1 Anderson like PowerPole Modular connectors
Communication Interface	​Smart RS232/USB Port Communication slot RJ 45	Support Windows Family, Linux, FreeDSB, etc. SNMP Card (independent to RS232) Built-in Power Surge, Lightning Protection Device
Environment	Operating Temperature Storage Temperature Humidity Attitude Noise	0 °C - 40 ° C -25  °C - +55 °C 0-90% non-condensing <1500 m. (derating while > 1500m) <50 dB (at 1 meter)
Safety Conformance		CE

All specifications subject to change without notice.
​​​​​​Custom-made specifications are acceptable.
​​​​​​​
​​​​​​​​​​​​​​

​​​​​​​

​​​​​​​
